Streamfeeder SI-1750

The Streamfeeder SI-1750 is designed to be a flexible feeding solution for packaging operations pursuing greater productivity through automation. Ideal for use with Wrapper, Cartoner, L-Sealer Infeed Conveyors, and other types of packaging equipment that require high performance feeding automation. The powerful Streamfeeder I-Quipped™ controller features an embedded microprocessor which provides an Information Management System and Host Communication.

Applications:
(click to view video)

Streamfeeder Wrapper / Cartoner Infeed Conveyor

  Features
  • Durable Steel construction
  • Quality precision parts
  • I-Quipped™ microprocessor system management controller
  • Real-time job indicators with resettable counter
  • Missed product detection
  • Passcode protection for system configurations
  • Systems I/O Interface
Technical Data
Maximum Product Size: 18 W x 12 L in (457.2 x 304.8 mm)

Minimum Product Size:
(with small product kit)

7.875 W x 3 L in (200 x 76.2 mm)
2 W x 3 L in (50.8 x 76.2 mm)

Min/Max Product Thickness: .003-.250 in (.076-6.35 mm)
Belt Speed: 5700 in/min (144,780 mm/min)
Electrical Requirements: 115/230vac, 60Hz, 3A
Weight: 90 lbs. (40.82 kg)
